PVC pipe machine is mainly used in the manufacture of plastic PVC pipes with various diameters and wall thickness;
The production line is composed of conical twin-screw extruder, vacuum calibration tank, haul-off, cutter and stacker etc
PVC Pipe Machine
Model: SJSZ51/105 SJSZ65/132 SJSZ65/132 SJSZ80/156 SJSZ92/188
Brand: Matrix Extrusion Technik
Code: 84772090
Specifications
| Diameter scope (mm) | 16-50 Dual | 16-63 Dual | 50-160 | 110-250 | 160-315 | 315-630 | 560-800 |
|---|---|---|---|---|---|---|---|
| Conical extruder | SJSZ51/105 | SJSZ65/132 | SJSZ65/132 | SJSZ80/156 | SJSZ80/156 | SJSZ92/188 | SJSZ105/216 |
| Extruder powder (KW) | 18.5 AC | 37 AC | 37 AC | 55 AC | 55 AC | 110 DC | 160 DC |
| Max. capacity (KG) | 120 | 250 | 250 | 350 | 350 | 800 | 1100 |
| Max. Lineal speed (m/min) | 10 | 15 | 8 | 3.5 | 3 | 1.2 | 1.3 |
Applications
1. Tap water piping engineering
2. Civil and municipal water supply and drainage
