Low energy consumption, easy to install, operate and maintain
Change the different diameter sieve, can get different size of final scrap.
Machine automatic stop when the cutting blades are exposed.
SWP Series Plastic Crusher
Model: SWP400 SWP500 SWP630
Brand: Matrix Extrusion Technik
Code: 84798200
Specifications
| Model | SWP400 | SWP500 | SWP 630 |
| Rotary blade diameter | 400mm | 500mm | 630mm |
| Quantity of rotary blade | 5pcs | 5pcs | 10pcs |
| Quantity of static blade | 2pcs | 2pcs | 4pcs |
| Motor power | 18.5kw | 22kw | 37KW |
| Size of mesh screen | 10mm | 10mm | 10mm |
| Feeding mouth | 390*350mm | 575*320mm | 620×470mm |
| Capacity | 150-250kg/h | 300-350kg/h | 500-650 |
| Weight | 1100kg | 1280kg | 1580kg |
| size | 1900*1200*2000 | 2500*1200*2000 | 2500×1200×2000 |
Applications
Crushing waste plastic pipe and plastic profile for purpose of recycling
